Deploying Rails applications has never been easier thanks to Kamal (formerly MRSK) and GitHub Actions. In this post, I’ll share working examples of how to set up automated deployments that will save you time and reduce deployment friction. Whether you’re deploying to a single server or managing multiple environments, this guide has you covered.

Kamal
brings Docker-powered deployments to Rails without the complexity of Kubernetes. Combined with
GitHub Actions, you get:

  • Zero-downtime deployments with automatic health checks
  • Push-to-deploy workflows from your main branch
  • Multi-environment support (staging, production)
  • Built-in rollback capabilities
  • No vendor lock-in – deploy to any VPS

Github Action Script

Example 1

Here’s a straightforward GitHub Actions workflow that deploys whenever you push to the main branch (by nbakush):

name: Deploy main branch
concurrency:
  group: production
  cancel-in-progress: true
on:
  push:
    branches:
      - main
  # or manually
  workflow_dispatch:
    # Required for secrets.GITHUB_TOKEN
permissions:
  packages: write
  contents: read
jobs:
  deploy:
    name: deploy
    runs-on: ubuntu-latest
    env:
      KAMAL_REGISTRY_PASSWORD: $
      KAMAL_REGISTRY_USERNAME: $
    strategy:
      matrix:
        node-version: [18.x]
    steps:
      - name: Push to Github Container Repository
        uses: Clipr-Group/ghcr-action@v1
        with:
          token: $
          platforms: linux/amd64,linux/arm64
      - name: Checkout code
        uses: actions/checkout@v4
      - name: Set up Ruby
        uses: ruby/setup-ruby@v1
        with:
          ruby-version: 3.3.0
          bundler-cache: true
      - name: Install Kamal
        run: gem install kamal
      - name: Connect to Tailscale (Optional)
        uses: tailscale/github-action@v3
        with:
          authkey: $
      - name: Release kamal lock
        run: kamal lock release
      - name: Run deploy command
        run: kamal deploy -P -v --version latest

Key Features of This Setup:

  • Concurrency control: Prevents multiple deploys from running simultaneously
  • Multi-platform builds: Supports both AMD64 and ARM64 architectures
  • Tailscale integration: Simplifies server access with friendly hostnames
  • Lock release: Ensures a clean state before deployment

Example 2

name: Deploy with Kamal
on:
  workflow_dispatch:
    inputs:
      environment:
        description: "Environment to deploy to"
        required: true
        default: "production"
        type: choice
        options:
          - production
          - staging
jobs:
  deploy:
    runs-on: ubuntu-latest
    environment: $
    env:
      DOCKER_BUILDKIT: 1
      RAILS_ENV: production
      SERVER_HOST: $
      KAMAL_REGISTRY_PASSWORD: $
      POSTGRES_PASSWORD: $
      RAILS_MASTER_KEY: $
      SECRET_KEY_BASE: $
    steps:
      - name: Checkout code
        uses: actions/checkout@v4
      - name: Set up Ruby
        uses: ruby/setup-ruby@v1
        with:
          ruby-version: "3.4.4"
          bundler-cache: true
      - name: Set up Docker Buildx
        uses: docker/setup-buildx-action@v3
      - name: Install Kamal
        run: gem install kamal
      - name: Set up SSH
        uses: webfactory/ssh-agent@v0.9.0
        with:
          ssh-private-key: $
      - name: Login to Docker Hub
        uses: docker/login-action@v3
        with:
          username: xxx
          password: $
      - name: Deploy with Kamal
        run: kamal deploy

Kamal Configuration (config/deploy.yml)

Here’s a production-ready Kamal configuration that includes a database and Redis:

# Name of your application
service: service-name
# Container image
image: xxx/xxx
# Deploy to these servers
servers:
  web:
    - <%= ENV["SERVER_HOST"] %>
proxy:
  app_port: 8000
# Registry configuration
registry:
  username: xxx
  password:
    - KAMAL_REGISTRY_PASSWORD
# Builder configuration
builder:
  arch: amd64
# Environment variables
env:
  clear:
    RAILS_ENV: production
    NODE_ENV: production
    PORT: 8000
    POSTGRES_HOST: service-name-db
    POSTGRES_PORT: 5432
    POSTGRES_DB: dbname
    POSTGRES_USER: username
    REDIS_URL: redis://service-name-redis:6379/1
    REDIS_HOST: service-name-redis
  secret:
    - RAILS_MASTER_KEY
    - SECRET_KEY_BASE
    - POSTGRES_PASSWORD
# Useful aliases
aliases:
  shell: app exec --interactive --reuse "bash"
  console: app exec --interactive --reuse "bin/rails console"
# Accessory services
accessories:
  db:
    image: postgres:16
    host: <%= ENV["SERVER_HOST"] %>
    port: 5432
    env:
      clear:
        POSTGRES_DB: dbname
        POSTGRES_USER: username
      secret:
        - POSTGRES_PASSWORD
    directories:
      - data: /var/lib/postgresql/data
  redis:
    image: redis:latest
    host: <%= ENV["SERVER_HOST"] %>
    port: 6379
    directories:
      - /var/lib/redis: /data

Required GitHub Secrets

Configure these secrets in your repository settings:

Essential Secrets:

  • KAMAL_REGISTRY_PASSWORD: Docker registry password
  • KAMAL_REGISTRY_USERNAME: Docker registry username (if using Docker Hub)
  • SSH_PRIVATE_KEY: For server access
  • SERVER_HOST: Your server’s IP or hostname

Rails-specific Secrets:

  • RAILS_MASTER_KEY: Rails credentials master key
  • SECRET_KEY_BASE: Rails secret key base
  • POSTGRES_PASSWORD: Database password

Optional:

  • TAILSCALE_AUTHKEY: For Tailscale VPN access (simplifies server management)

💡 Pro Tips

  1. Use Tailscale for Simplified Networking
    Instead of managing IP addresses, Tailscale lets you use friendly hostnames.
    Optional but highly recommended for teams:

    - name: Connect to Tailscale
  uses: tailscale/github-action@v3
  with:
    authkey: $

  2. Implement Deployment Locks
    Always release locks to prevent stuck deployments:

    - name: Release kamal lock
  run: kamal lock release
  3. Use Concurrency Groups
    Prevent deployment collisions:
    concurrency:
  group: production
  cancel-in-progress: true
  4. Separate Accessories Configuration
    Keep your database and Redis as Kamal accessories for easier management and persistence.

Combining Kamal with GitHub Actions provides a robust and cost-effective deployment pipeline that rivals enterprise solutions. You get the simplicity of Heroku-style deploys with the flexibility and control of your own infrastructure.
The beauty of this setup lies in its simplicity—push your code, and GitHub Actions, along with Kamal, handle the rest. No Kubernetes complexity, no vendor lock-in, just straightforward Docker deployments that work.
